FortiOS 8.0 FortiAI Assistant Technical Insight

Summary

FortiOS 8.0 deeply embeds FortiAI-Assist intelligent assistant into the FortiGate operating system for the first time, providing network security administrators with generative AI-powered operational assistance capabilities. This article provides a systematic deep analysis of FortiAI's technical architecture, deployment methods, business workflows, and licensing models based on FortiOS 8.0 official documentation, helping technical teams fully understand this new feature.

Key Finding: FortiOS 8.0's FortiAI is not a standalone web application interaction assistant, but a RAG (Retrieval-Augmented Generation) system deeply integrated with FortiGate, supporting documentation Q&A, troubleshooting diagnostics, and CLI command generation and execution. The system supports both FortiAI and OpenAI as AI providers, and uses a subscription-based Token billing model.

1. Product Positioning and Functional Overview

1.1 FortiAI-Assist Positioning in FortiOS 8.0

According to FortiOS 8.0 official documentation:

FortiAI-Assist is now embedded in FortiOS, and FortiOS includes the FortiAI assistant and CLI Code Lab tool to provide RAG-enhanced documentation support, automated diagnostic analysis, and CLI script execution.

FortiAI-Assist is an AI assistance tool launched by Fortinet in FortiOS 8.0, with core positioning including three aspects:

1.2 Comparison with FortiAI in Other Fortinet Products

It is important to note that: FortiOS 8.0's FortiAI has functional differences compared to FortiAI in FortiWeb, FortiADC, and FortiManager.

2. Device Deployment Guide (Step by Step)

2.1 Hardware and Licensing Requirements

According to official documentation, FortiAI-Assist has clear requirements for hardware and subscriptions:

Supported FortiGate Models

Important Limitation: FortiGate models with memory equal to or less than 2GB do not support FortiAI-Assist functionality.

Network Requirements

• FortiGate device must be able to access the Internet
• For establishing communication with FortiAI cloud service or OpenAI API

2.2 Deployment Steps

Step 1: Verify License Status

Before enabling FortiAI, confirm that the FortiGate device is registered and bound to a valid FortiCare Premium license:

# Check license status via CLI diagnose sys license list

Step 2: Select and Enable AI Provider

FortiOS 8.0 supports two AI providers, administrators can choose based on requirements:

Method A: Use FortiAI (Fortinet Native AI)

1. In the FortiOS GUI top banner, click the FortiAI icon
2. In the popup AI Model Selection dialog, select FortiAI
3. Click OK to confirm

FortiAI provider includes the following features:

• 2,000,000 starting Tokens per device per month
• Additional Tokens can be purchased as needed
• Purchased Tokens are shared across all devices under the same FortiCare account

Method B: Use OpenAI (Third-party AI)

1. Click the FortiAI icon in the GUI
2. Select OpenAI and fill in configuration information: API Key, Model name (such as gpt-5.2), Project ID, Organization ID

Or configure via CLI:

config system admin    edit "admin"        set vdom "root"        set accprofile "super_admin"        set gui-llm-provider openai        set openai-api-key <your-api-key>        set openai-api-key-part2 <key-part2>        set openai-model "gpt-5.2"        set openai-project-id "<project-ID>"        set openai-org-id "<organization-ID>"    next end

Note: When using OpenAI, Tokens are billed directly from the OpenAI account, and FortiOS does not provide usage tracking.

Step 3: Configure Administrator Access Permissions

FortiAI-Assist access permissions are controlled through Admin Profiles:

GUI Configuration Method:

1. Navigate to System > Admin Profiles
2. Double-click the admin profile to edit (such as prof_admin)
3. Enable/disable Allow using AI Assistant
4. Click OK to save

CLI Configuration Method:

config system accprofile    edit "admin-withAI"        set comments "Admin with AI Assistant access"        set secfabgrp read-write        # ... other permission settings ...        set gui-ai-assistant enable    next end

Permission Notes:

• Even if the admin profile disables AI Assistant, the FortiAI icon remains visible in the GUI banner, but administrators cannot submit queries or receive responses
• The `super_admin` profile cannot edit this setting (always allowed)
• FortiAI uses the same permissions as the logged-in administrator when calling FortiOS REST API

Step 4: (Optional) Enable Data Masking

Sensitive data masking is an important privacy protection feature:

1. In the FortiAI chat window, click the data masking icon
2. When enabled, the following sensitive information will be replaced with placeholders before sending to the AI provider: IP addresses, MAC addresses, Email addresses, Phone numbers, URLs

Enabled state: Chat window shows ✓ icon; Disabled state: Shows × icon

Step 5: Access CLI Code Lab

CLI Code Lab is FortiAI's companion tool for generating, editing, and executing CLI commands:

Access Methods:

• Method 1: Access from GUI banner - Click CLI Console > CLI Code Lab
• Method 2: Access from FortiAI returned commands - When FortiAI returns CLI commands, click the Edit button to open CLI Code Lab

CLI Code Lab interface includes: Left pane (editable CLI command input area), Right pane (command execution output area), Execute button (execute commands, requires secondary confirmation), Commit changes button (save configuration changes)

3. Business Process Deep Analysis

3.1 User Interaction Process

FortiAI-Assist's user interaction follows a Q&A → Analysis → Execution three-stage model:

• Stage 1 - Q&A Interaction: User inputs natural language queries or instructions
• Stage 2 - System Analysis: LLM + RAG processing, local data analysis
• Stage 3 - Configuration/Diagnostic Execution: CLI Code Lab executes commands

3.2 System Processing Flow

3.2.1 Documentation-Based Q&A Process

When users ask product operation questions, the system uses a RAG architecture:

1. User query
2. Query vectorization (embedding model processing)
3. Document retrieval (matching relevant document fragments)
4. Context assembly
5. LLM generates response
6. Returns response with sources

According to official documentation: "When FortiAI uses FortiAI as the AI provider, the following FortiOS documents are used to provide answers: FortiOS Administration Guide, FortiOS CLI Reference. FortiAI also checks its answers against the FortiGate to ensure the results are suitable for the specific model."

RAG Knowledge Base includes: FortiOS Administration Guide, FortiOS CLI Reference

Model Validation Mechanism: Generated responses are cross-validated with the target FortiGate device to ensure generated configuration commands are applicable to that specific model.

3.2.2 Diagnostic Analysis Process

For troubleshooting scenarios, the system supports a hybrid analysis mode:

• User describes problem → FortiAI returns diagnostic CLI commands
• User pastes debug output/log files → FortiAI analyzes and identifies root cause

Typical Troubleshooting Example:

User input: "troubleshoot issue ipsec vpn tunnel to-headoffice is down"

System returns:

Your debug is definitive: IKEv2 AUTH fails - authentication failed - PSK auth failed: probable pre-shared key mismatch - initiator receives AUTHENTICATION_FAILED

3.2.3 CLI Command Generation and Execution Process

1. User inputs natural language requirement, example: "configure this fgt to block social media"
2. LLM generates CLI commands
3. User supplements environment information, example: "lan interface port2, update existing policy 1"
4. LLM adjusts commands based on context
5. User clicks Edit to open CLI Code Lab
6. Edit commands in CLI Code Lab and click Execute
7. System executes commands after secondary confirmation
8. Execution results displayed in right pane
9. User clicks Commit changes to save configuration

3.3 Session Management Mechanism

Token Consumption and Context

According to official documentation: "Because the FortiAI assistant uses session history to inform its responses, queries that are a part of a long session will use more tokens than new conversations."

Context Management Rules:

• Historical messages in the same session are sent to the LLM as context
• When message history reaches the limit, it will be compressed (may lose some information)
• Compressed history will reduce response accuracy
• LLM does not remember content from different sessions

Recommendation: When handling unrelated tasks, create a new session to get more accurate responses.

Chat History Management

4. Large Model Architecture Deep Analysis

4.1 Dual AI Provider Architecture

FortiOS 8.0's FortiAI adopts a dual-provider architecture, providing flexibility choices for administrators:

4.1.1 FortiAI Provider (Fortinet Native)

4.1.2 OpenAI Provider (Third-party)

CLI Configuration Options:

config system admin    edit <admin-name>        set gui-llm-provider {fortiai | openai}        set openai-api-key <password>        set openai-api-key-part2 <password>        set openai-model <string>        set openai-project-id <string>        set openai-org-id <string>    next end

4.2 RAG Architecture Analysis

4.2.1 RAG Component Composition

FortiAI-Assist's RAG system contains the following core components:

4.2.2 Retrieval Augmentation Mechanism

Document Sources: Official documentation clearly states: "When FortiAI uses FortiAI as the AI provider, the following FortiOS documents are used to provide answers: FortiOS Administration Guide, FortiOS CLI Reference."

RAG Workflow:

1. Indexing Phase: Chunking and vectorizing official documentation
2. Retrieval Phase: After user query vectorization, match Top-K relevant fragments with vector database
3. Assembly Phase: Assemble user query + retrieved fragments + system prompt into complete prompt
4. Generation Phase: LLM generates response based on assembled context
5. Validation Phase: Check if generated commands are applicable to target FortiGate model

4.2.3 Local Data Analysis Capability

Different from pure documentation Q&A, FortiAI also supports local data analysis:

4.3 Deployment Mode Analysis

4.3.1 Cloud Processing Mode

Characteristics:

• LLM inference completed in Fortinet cloud
• Requires Internet connection
• Supports RAG document retrieval

4.3.2 Direct Third-party Mode

Characteristics:

• LLM inference completed on OpenAI servers
• No FortiOS documentation knowledge base enhancement
• Need to manage OpenAI account and fees yourself

5. Authorization and Billing Model

5.1 Authorization Requirements

According to official documentation, FortiAI-Assist authorization requirements are as follows:

FortiGate Hardware Devices

FortiGate-VM S-series

Unsupported Scenarios

5.2 Token Billing Mechanism

Token Consumption Rules

Official Explanation: "When you use the FortiAI assistant, the text in both the prompt (input) and the response (output) is processed as tokens." "Because the FortiAI assistant uses session history to inform its responses, queries that are a part of a long session will use more tokens than new conversations."

Token Best Practices

Token saving strategies recommended by official documentation:

Token Exhaustion Handling

When monthly Token quota is exhausted:

• FortiAI access is temporarily suspended
• Need to wait for next billing cycle reset
• Additional purchased Tokens are not subject to this limit

5.3 Billing Comparison of Different AI Providers

6. Security and Privacy Protection

6.1 Data Masking Mechanism

FortiAI supports sensitive information masking before sending data to AI providers:

Masked Data Types

Masking Control

• Click icon to toggle in FortiAI chat window
• ✓ icon = Masking enabled
• × icon = Masking disabled
• Recommend always enabling in scenarios containing sensitive information

6.2 Permission Control

Administrator Permission Isolation

"FortiAI calls the FortiOS REST APIs with the same permissions as the logged in administrator."

This means:

• AI assistant cannot exceed admin profile permissions
• Even if high-privilege commands are generated, execution is still restricted by permissions
• Different administrators see different scopes of responses based on their profiles

Admin Profile Configuration

7. Practical Application Scenario Examples

7.1 Scenario 1: IPsec VPN Tunnel Troubleshooting

Topology Background: Two FortiGates configured with IPsec site-to-site VPN, tunnel status is down

Troubleshooting Steps:

1. In FortiAI chat window, input: "troubleshoot issue ipsec vpn tunnel to-headoffice is down"
2. FortiAI returns diagnostic commands for collecting IKE debug logs
3. Administrator executes commands in SSH session, collects log output
4. Paste log output back to FortiAI chat window
5. FortiAI analyzes logs and returns diagnostic results

7.2 Scenario 2: Configure Firewall Policy Using OpenAI

Requirement: Block social media access through web filter

Operation Steps:

1. Enable OpenAI as AI provider
2. Input natural language requirement: "configure this fgt to block social media by webfilter"
3. FortiAI returns CLI commands, can supplement information to optimize: "lan interface port2. wan interface port1. update existing policy 1 instead of creating a new one"
4. Click Edit to open commands in CLI Code Lab
5. Edit commands and click Execute
6. System executes after confirmation, output results displayed in right pane
7. Click Commit changes to save configuration

8. Technical Specifications Summary

8.1 System Requirements

8.2 CLI Command Summary

Enable AI Assistant Permission

config system accprofile    edit <profile-name>        set gui-ai-assistant {enable | disable}    next end

Configure OpenAI Provider

config system admin    edit <admin-name>        set gui-llm-provider {fortiai | openai}        set openai-api-key <password>        set openai-api-key-part2 <password>        set openai-model <string>        set openai-project-id <string>        set openai-org-id <string>    next end

8.3 Token Quota (FortiAI Provider)

9. Summary and Recommendations

9.1 Core Value

FortiOS 8.0's FortiAI-Assist brings the following core values to FortiGate administrators:

9.2 Selection Recommendations

9.3 Notes

1. Token Management: For high-frequency usage scenarios, recommend enabling data masking and streamlining sessions
2. Permission Control: Recommend disabling AI Assistant for non-administrator accounts
3. Network Security: Ensure HTTPS communication security between FortiGate and AI services
4. Compliance Requirements: When using OpenAI, pay attention to data cross-border compliance

References

1. Fortinet. "FortiAI assistant and CLI Code Lab" - FortiOS 8.0.0 New Features. https://docs.fortinet.com/document/fortigate/8.0.0/new-features/018007/fortiai-assistant-and-cli-code-lab
2. Fortinet. "FortiAI Assistant for FortiADC 8.0.2" - FortiADC New Features. https://fortinetweb.s3.amazonaws.com/docs.fortinet.com/v2/attachments/6b854031-36c8-11f0-a9d0-d2b0d2e22f7d/fortiadc-v8.0.2-new-features.pdf
3. Fortinet. "Protecting GenAI access using application control" - FortiGate Administration Guide. https://docs.fortinet.com/document/fortigate/latest/administration-guide/679448/protecting-genai-access-using-application-control
4. Fortinet. "FortiOS 8.0 New Features Overview" - FortiGate / FortiOS. https://docs.fortinet.com/document/fortigate/8.0.0/new-features
5. Fortinet. "Using FortiAI" - FortiADC Administration Guide. https://docs.fortinet.com/document/fortiadc/latest/administration-guide/330090/using-fortiai
